McKinney QC-R001 ElectroLynx Quick Connect Service Repair Kit

The McKinney QC-R001 ElectroLynx Service Repair Kit is the essential master toolkit for technicians, facility managers, and security contractors working with electrified door hardware. Designed specifically for the maintenance and on-site repair of ElectroLynx systems, this kit provides a comprehensive selection of connectors and terminals used in high-traffic commercial environments. It serves as a vital solution for door restoration, allowing you to fix damaged wiring or custom-pin retrofit harnesses without replacing expensive hardware components.

This all-in-one repair solution ensures that electrified locks, hinges, and exit devices maintain a secure, factory-standard communication link. By utilizing the components in the QC-R001, you can perform a professional solution for door surface repair and electrical troubleshooting on-site, minimizing door downtime in critical facilities like schools, hospitals, and government buildings.

Kit Contents & Components

The QC-R001 is organized for efficiency and contains the most frequently used parts in the ElectroLynx ecosystem:

• Molex Receptacles (Female): 10 each of 2-circuit, 4-circuit, and 8-circuit housings.

• Molex Plugs (Male): 10 each of 2-circuit, 4-circuit, and 8-circuit housings.

• Terminals: A full assortment of corresponding male and female terminals (pins) for precise electrical contact.

• Extraction Tool: A specialized tool to safely remove pins from housings without damaging the connector.

• Pinning Assembly Guide: A detailed reference for correct wire placement to ensure error-proof connectivity.


Key Features & Benefits

• Universal ElectroLynx Repair: Compatible with all ASSA ABLOY brand "plug-and-play" hardware, including McKinney, Sargent, Corbin Russwin, and Yale.
• Streamlined Retrofitting: The perfect solution for door security upgrades, allowing you to pin standard wire cables to match existing ElectroLynx-ready hardware.
• Durable & Conductive: High-quality Molex components provide a permanent solution for door edge reinforcement for electrified paths, resisting vibration and physical wear.
• Reduced Maintenance Costs: Eliminates the need to buy individual wire harnesses by providing the parts necessary for field-level connector replacement.
• Professional Organization: Housed in a durable, partitioned carrying case for easy identification and transport between job sites.

Technical Details & Specifications

• Brand: McKinney (ASSA ABLOY)
• Model Number: QC-R001
• Compatibility: 2, 4, and 8-circuit ElectroLynx systems.

• System Requirements: For a complete professional installation, the QC-R003 hand crimp tool is required (sold separately).
• Installation Tip: When repairing electrified hinges, ensure all wires are neatly managed within the door raceway.

Why Choose the McKinney QC-R001?

The McKinney QC-R001 is the professional’s choice for maintaining 100% system uptime in electrified openings. While manual splicing and electrical tape can lead to system failure, the ElectroLynx Repair Kit delivers the factory-standard performance required for life-safety and high-security access control. It offers a permanent and cost-effective solution for door security, providing the essential parts for precise, error-proof electrical terminations every time.
