Versatile Functionality & High-Strength Mounting
The Hager 47PT is a "Less Mortise Cylinder" model, designed to be paired with a Hager 3902 mortise cylinder with a standard cam (sold separately). This allows for seamless integration into your existing master key system. To ensure a permanent, high-strength installation, the trim includes thru bolts as standard hardware, creating a rigid connection through the door that resists sagging and tampering.
Key Features
- ADA Compliant Thumbpiece: Ergonomic design meets A117.1 accessibility standards.
- Rugged Construction: Features a heavy-duty steel plate and a durable pull handle with a 1-3/4" projection.
- Standard Door Prep: Includes a retaining cup designed for standard 161 door preparations.
Technical Specifications
| Feature | Specification |
| Model Number | Hager 47PT |
| 05 (Entrance by Thumbpiece / Classroom) | |
| Certification | |
| Compatibility | Hager 4700 Series Rim and Vertical Rod Devices |
| Plate Size | 3" x 11" (76 mm x 298.5 mm) |
| Cylinder Requirements | Requires 3902 Mortise Cylinder (Sold Separately) |
| Fasteners | Thru Bolts, Wood, and Machine Screws |
| Warranty | 5-Year Limited Manufacturer Warranty |
Available Finish Options
Select from several architectural finishes at DoorwaysPlus.com to match your facility's design:
- Satin Stainless Steel (US32D): Exceptionally durable and corrosion-resistant for high-traffic areas.
- Sprayed Aluminum (ALM): A modern, professional look for contemporary office and school frames.
- Sprayed Dark Bronze (DBZ): A classic, professional finish for traditional commercial storefronts.
- Bright Brass (US3): A polished, traditional finish for upscale institutional entries.
| Door Handing | RHR or LHR |
| Brand | Hager |
| Series | Hager - 4700 Series |
| Finish with BHMA code | 630 - US32D Satin Stainless |
| Exit Device Trim Function | Classroom |
| Trim Design | Grip Pull |
