Hager 1760 4" x 4" Stainless Steel Single Acting Spring Hinge
The Hager 1760 is a premium residential weight spring hinge designed to provide reliable automatic closing for interior and exterior doors. Crafted entirely from stainless steel with matching internal components, this hinge is the ultimate solution for homes in coastal areas or high-humidity environments where standard steel hardware would fail. Its single acting spring mechanism ensures that doors return to a closed position, improving energy efficiency and security.
Corrosion-Resistant Self-Closing Performance
Unlike standard plated hinges, the Hager 1760 features a non-ferrous stainless steel construction (ANSI K51071F). This makes it impervious to rust and pitting, even when exposed to salt air. Designed specifically for residential use, it offers a sleek US32D Satin Stainless Steel finish and a square corner profile that fits most modern home door preps. Whether you are installing a door to a garage or a beachfront patio, this hinge provides the "heavy-duty" protection of stainless steel in a residential-sized package.
Installation and Compatibility
For the best results, Hager recommends using all spring hinges or a combination of spring hinges and ball bearing hinges—do not use plain bearing hinges in conjunction with this product. Please note that while many hinges look identical, screw hole patterns can vary by manufacturer. Always verify your current door and frame prep against the Hager template before ordering to ensure a perfect fit.
Technical Specifications
| Feature | Specification |
| Model Number | Hager 1760 |
| Dimensions | 4.0" x 4.0" (102mm x 102mm) |
| Hinge Type | Single Acting Spring Hinge |
| Material | Stainless Steel with Stainless Steel Components |
| Standards | ANSI K51071F Compliant |
| Gauge (Thickness) | 0.106" (Residential Weight) |
| Corner Type | Square Corner |
| Packaging | 2 hinges per box (Pricing is Per Hinge) |
| Fasteners | 3/4 x 9 FH Stainless Steel Wood Screws Included |
Usage and Loading Guidelines
- Automatic Closing: Designed for doors that require self-closing functionality.
- Environmental Factors: Strong drafts, heavy carpeting, or thick weatherstripping may require the use of additional spring hinges to ensure a full latch.
- Versatility: Tension is adjustable, though full tension may not be required on every hinge in a set.
- Commercial vs. Residential: This is a residential weight hinge (.106 gauge). For high-traffic institutional use, a thicker commercial-grade spring hinge (.134 gauge or higher) is recommended.
How to tell the difference between Residential Hinge and a Commercial Hinge
| General - US Finishes | US32D - Satin Stainless Steel/ 630 |
| Brand | Hager |
| Hinge Height | 4.0" Hi |
| Hinge Width | 4.0" Wi |
| Hinge Grade/Thickness | Residental Wt .085 to .106 |
| Hinge Type | Full Mortise, Spring Hinge |
| Spring Hinge Type | Single Acting |
| Base Material | Stainless Steel |
| Hinge Corners | Square |
