McKinney HTA2314 4-1/2 x 4 Five-Knuckle Standard Weight Hospital Tip Hinge — Full Mortise Stainless Steel Ball Bearing Butt Hinge
The McKinney HTA2314 is a full mortise, five-knuckle, standard weight stainless steel ball bearing butt hinge with hospital tips, sized 4-1/2 inches by 4 inches. Designed for demanding commercial and institutional door applications, this hinge combines the cleanability and corrosion resistance of stainless steel construction with the smooth, low-friction performance of ball bearings and the distinctive hospital tip profile — also commonly referred to as a hospital-style tip or sanitary tip — which eliminates exposed fastener points and sharp corners to support hygienic environments and reduce injury risk. As a full mortise hinge, both leaves recess flush into the door edge and frame, providing a clean, professional installation consistent with commercial door hardware standards. Part number HTA2314 is a genuine McKinney hinge, a brand recognized across the architectural hardware industry for precision-manufactured butt hinges used in commercial, institutional, healthcare, and high-traffic settings.
Institutional Grade Features & Benefits
- Hospital Tip Profile: The hospital-style (sanitary) tip design eliminates protruding fastener points and sharp corners at the top and bottom of the hinge barrel, supporting hygienic maintenance and reducing snag and injury hazards — a standard specification in healthcare, educational, and institutional facilities.
- Five-Knuckle Construction: The five-knuckle barrel configuration provides superior strength distribution along the hinge pin, contributing to long-term stability and reduced play in the door over time compared to three-knuckle designs.
- Ball Bearing Operation: Precision ball bearings within the knuckles deliver smooth, low-effort door swing and reduce friction-related wear, making this hinge well-suited for high-cycle, heavy-use openings.
- Full Mortise Design: Both leaves mortise flush into the door edge and frame face, producing a clean finished appearance and secure mechanical connection — the preferred installation method for commercial and institutional wood and hollow metal doors.
- Stainless Steel Material: Stainless steel construction delivers excellent corrosion resistance and a cleanable surface, supporting installations in moisture-prone, frequently sanitized, or high-humidity environments.
- Standard Weight Classification: Sized and specified for standard weight commercial door applications, providing the appropriate mass and leaf thickness for the intended door weight and frequency-of-use category.
- Precise Leaf Thickness: Steel leaf gauge of 0.134 in. delivers consistent performance within the standard weight class, as published in the McKinney full-line catalog.
- 4-1/2 x 4 Inch Size: A widely specified hinge size for standard commercial door heights and weights, compatible with common commercial door and frame preparations.
Technical Specifications
- Brand: McKinney
- Part Number: HTA2314
- Part Type: Full Mortise Ball Bearing Butt Hinge
- Hinge Size: 4-1/2 in. x 4 in.
- Knuckle Count: Five-Knuckle
- Weight Class: Standard Weight
- Tip Style: Hospital Tip (Sanitary Tip)
- Bearing Type: Ball Bearing
- Material: Stainless Steel
- Gauge / Leaf Thickness: 0.134 in.
- Mounting Type: Full Mortise
Technical Details
| Feature | Details |
|---|---|
| Brand | McKinney |
| Model / Part Number | HTA2314 |
| Part Type | Full Mortise Ball Bearing Butt Hinge |
| Hinge Size | 4-1/2 in. x 4 in. |
| Knuckle Count | Five-Knuckle |
| Weight Class | Standard Weight |
| Tip Style | Hospital Tip (Sanitary Tip) |
| Bearing Type | Ball Bearing |
| Material | Stainless Steel |
| Gauge / Leaf Thickness | 0.134 in. |
| Mounting Type | Full Mortise |
Documentation
| Brand | McKinney |
| General - US Finishes | US32D - Satin Stainless Steel/ 630 |
| Hinge Type | Full Mortise |
| Hinge Mounting | Full Mortise |
| Door Handing | Field Reversible |
| Hinge Height | 4.5" Hi |
| Hinge Width | 4.0" Wi |
| Hinge Grade/Thickness | Standard Wt .119 to .146 |
| Hinge Corners | Square |
| Hinge Knuckle | 5 Knuckles |
| Base Material | Stainless Steel |
| Hinge Options | HT (Hospital Tip) |
| Part Type | Hinge |
