McKinney TA2771 4-1/2 Inch Five-Knuckle Standard Weight Full Surface Hinge
The McKinney TA2771 is a 4-1/2 inch five-knuckle standard weight full surface hinge designed for doors and frames where mortising is not practical or desired. As a full surface hinge, both leaves mount directly onto the face of the door and the face of the frame — no chiseling or routing required — making it an ideal solution for channel-iron frames, hollow metal frames, and similar applications where a surface-applied hinge is the correct specification. The TA2771 is a trusted McKinney hinge widely specified in commercial and institutional door hardware projects.
Institutional Grade Features & Benefits
- Full Surface Mount: Both the door leaf and the frame leaf apply directly to the surface of the door and frame faces, eliminating the need for mortising on either side — simplifying installation and reducing labor on channel-iron and comparable frame types.
- Five-Knuckle Construction: The five-knuckle barrel design provides a traditional commercial aesthetic along with smooth, consistent pivot action across the full swing of the door.
- Standard Weight: Engineered as a standard weight hinge, the TA2771 is appropriately matched to standard commercial door and hardware assemblies where a heavyweight or extra-heavyweight hinge is not required.
- 4-1/2 Inch Hinge Size: The 4-1/2 inch leaf height is a widely specified commercial hinge dimension, compatible with standard commercial door heights and common hardware schedules.
- McKinney Quality: McKinney is a long-established, specification-grade hinge manufacturer. The TA2771 is part of a line engineered for reliable, long-term performance in commercial door openings.
- Channel-Iron & Surface-Frame Applications: Specifically suited for channel-iron frames and other frame profiles where a surface-applied hinge is the correct hardware solution, the TA2771 eliminates the need for frame prep typically associated with mortise hinges.
Technical Details
| Feature | Details |
|---|---|
| Brand | McKinney |
| Part Number | TA2771 |
| Part Type | Hinge |
| Hinge Type | Full Surface |
| Knuckle Count | Five-Knuckle |
| Weight Class | Standard Weight |
| Hinge Size | 4-1/2 Inch |
| Frame Compatibility | Channel-iron frames and similar surface-mount frame types |
| Mount Method | Both leaves surface-applied to door and frame faces (no mortising) |
Documentation
- McKinney Catalog / Product Page - TA2771
- No manufacturer cut sheet is published for this model in the McKinney document library; the catalog page above carries the spec.
| Brand | McKinney |
| General - US Finishes | US26D - Satin Chrome |
| Hinge Type | Full Surface |
| Hinge Mounting | Full Surface |
| Door Handing | Field Reversible |
| Hinge Height | 4.5" Hi |
| Hinge Grade/Thickness | Standard Wt .119 to .146 |
| Hinge Corners | Square |
| Hinge Knuckle | 5 Knuckles |
| Base Material | Steel |
| Part Type | Hinge, Hinge |
