McKinney TA386 NRP Concealed Bearing Hinge | 4-1/2" x 4" Heavy Weight Stainless Steel
The McKinney TA386 NRP is an industrial-strength, full-mortise architectural hinge engineered for high-security and high-traffic commercial environments. Combining a sleek 3-knuckle profile with Non-Removable Pin (NRP) technology and a heavy-duty stainless steel base, this hinge is the definitive solution for door security on out-swinging doors. It offers a sophisticated, clean aesthetic for hospitals, schools, and coastal facilities while ensuring the door cannot be removed from the frame even if the hinge barrels are exposed.
Crafted from high-grade Stainless Steel (US32D), the TA386 NRP provides maximum corrosion resistance and structural integrity. Featuring concealed vertical and lateral thrust twin anti-friction bearings, it ensures exceptionally smooth operation under heavy loads. The NRP feature includes a specialized set screw driven into the hinge barrel that is inaccessible when the door is closed, preventing unauthorized pin removal. This hinge is a vital component for any solution for door restoration, providing a professional-grade security upgrade with a heavy .180 gauge thickness.
Key Features & Performance
- NRP High-Security Locking: The Non-Removable Pin is an essential solution for commercial door security, specifically designed for exterior or outward-swinging doors where forced entry protection is critical.
- Heavy-Weight Construction: Built with a .180 gauge thickness, this hinge is engineered to withstand the rigors of high-traffic institutional use without sagging or failing.
- Corrosion-Resistant US32D Finish: Solid stainless steel construction makes this an ideal solution for door restoration in laboratories, coastal environments, or sterile medical facilities.
- Concealed Anti-Friction Bearings: Twin bearings are hidden within the joints to manage heavy thrust loads, acting as a permanent solution for door edge reinforcement.
- Modern 3-Knuckle Design: Features a contemporary look with a flush pin and non-rising stainless steel pin, providing a seamless profile for high-end architectural projects.
Technical Details & Specifications
- Brand: McKinney (ASSA ABLOY)
- Model Number: TA386 NRP
- Dimensions: 4-1/2" Height x 4" Width (Full Mortise)
- Material: Stainless Steel (Base Material and Pin)
- Finish: US32D (630) Satin Stainless Steel
- Security Feature: NRP (Non-Removable Pin) Set Screw
- Bearing Type: Concealed Vertical & Lateral Thrust (TA Prefix)
- Thickness: Heavy Weight .180 Gauge
- ANSI Number: A5111
- Fasteners Included: Furnished with All Wood Screws (1-1/4" x 12 FPHW) and All Machine Screws (1/2" x 12-24 FPHM). For high-use hollow metal doors, ensuring a rigid mount with thru bolts or precision machine screws is recommended for long-term alignment and security.
Why Choose the McKinney TA386 NRP?
The McKinney TA386 NRP is the professional’s choice for projects that demand the perfect balance of architectural elegance, weather resistance, and heavy-duty performance. While standard hinges may show wear or be vulnerable to tampering, the concealed bearing technology and NRP security of the TA386 safeguard your facility for the long term. It offers a permanent and cost-effective solution for door security, delivering industrial-grade reliability and a polished, high-end appearance.
| General - US Finishes | US32D - Satin Stainless Steel/ 630 |
| Brand | McKinney |
| Hinge Height | 4.5" Hi |
| Hinge Grade/Thickness | Heavy Wt .180 to .190 |
| Hinge Width | 4.0" Wi |
| Hinge Type | Full Mortise |
| Hinge Options | Concealed Bearing, NRP (Non Removable Pin) |
| Base Material | Stainless Steel |
| Hinge Corners | Square |
