McKinney TA795 4-1/2" Swing Clear Hinge | Full Mortise Three-Knuckle Heavy Weight Ball Bearing Reversible
McKinney TA795 4-1/2 three-knuckle heavy weight reversible swing clear hinge.
Lead time: Normally ships in 2-3 business days via McKinney QuickShip; current lead time confirmed at order acknowledgment.
Tags :
McKinney TA795 4-1/2 Swing Clear Hinge | Full Mortise Three-Knuckle Heavy Weight Ball Bearing Reversible
The McKinney TA795 is a full mortise, three-knuckle, heavy weight ball bearing swing clear hinge designed to swing a door fully clear of the door opening, providing a maximized barrier-free clear width. The TA795 is reversible, meaning a single hinge works for both left-hand and right-hand door applications without requiring separate parts. This makes it an efficient, flexible choice for projects where accessible, unobstructed passage is a priority. As a full mortise hinge, the TA795 installs flush into mortised cutouts on both the door edge and the door frame, delivering a clean, professional finish consistent with commercial and institutional door hardware standards.
Institutional Grade Features & Benefits
- Swing Clear Design: The offset knuckle geometry swings the door panel completely clear of the door opening, maximizing the usable clear width — a critical requirement for accessible and ADA-compliant doorway configurations.
- Full Mortise Installation: Both hinge leaves are recessed flush into the door edge and frame rabbet, providing a secure, low-profile fit that is standard in commercial door and frame assemblies.
- Three-Knuckle Construction: The three-knuckle design is a hallmark of heavy-duty commercial hinges, offering a clean silhouette while maintaining structural integrity under demanding use conditions.
- Heavy Weight Ball Bearing: Precision ball bearings are integrated into the knuckle assembly to reduce friction, support heavier door weights, and deliver smooth, consistent operation over extended service life.
- Reversible Handing: The TA795 is fully reversible, eliminating the need to specify or stock separate left-hand and right-hand versions — simplifying procurement and reducing job-site inventory.
- 4-1/2 Inch Size: The 4-1/2" hinge height is a widely specified dimension for standard commercial door applications, compatible with typical hollow metal and wood door assemblies.
Applications
The McKinney TA795 swing clear hinge is well suited for doorways where maximizing the clear opening width is essential. Swing clear hinges are commonly specified in healthcare facilities, educational buildings, government buildings, and any commercial or institutional project where barrier-free access and accessible doorway widths are required. The reversible, heavy weight ball bearing design supports high-cycle, heavy-traffic door environments.
Technical Details
| Feature | Details |
|---|---|
| Brand | McKinney |
| Model / Part Number | TA795 |
| Part Type | Full Mortise Swing Clear Hinge |
| Knuckle Configuration | Three-Knuckle |
| Bearing Type | Heavy Weight Ball Bearing |
| Hinge Size | 4-1/2 Inch |
| Handing | Reversible (Left-Hand and Right-Hand) |
| Function | Swings door fully clear of the opening to provide a barrier-free clear width |
| Installation Type | Full Mortise |
Documentation
| Brand | McKinney |
| General - US Finishes | US26D - Satin Chrome |
| Hinge Type | Swing Clear |
| Hinge Mounting | Full Mortise |
| Door Handing | Field Reversible |
| Hinge Height | 4.5" Hi |
| Hinge Width | 4.5" Wi |
| Hinge Grade/Thickness | Heavy Wt .180 to .190 |
| Hinge Corners | Square |
| Hinge Knuckle | 3 Knuckles |
| Base Material | Steel |
| Part Type | Hinge |
