McKinney 5540 Heavy Weight Reinforcing Pivot — 4 Inch | Stainless Steel
The McKinney 5540 is a 4-inch heavy weight reinforcing pivot engineered for use with pivot-hung doors. Designed to carry and reinforce the load at the top or intermediate pivot point, this pivot is built for high-frequency openings where structural support and long-term durability are critical. Finished in stainless steel, the McKinney 5540 delivers corrosion resistance and a clean, professional appearance suited to demanding commercial and institutional door applications.
Institutional Grade Features & Benefits
- Heavy Weight Load Capacity: Engineered specifically to carry and reinforce the structural load at the top or intermediate pivot point, making it an ideal choice for heavy pivot-hung doors subject to frequent use.
- High-Frequency Performance: Built to withstand the demands of high-cycle, high-traffic openings where standard pivots may fatigue or fail prematurely.
- Top or Intermediate Pivot Point Compatibility: Versatile placement options allow the 5540 to function at either the top or intermediate position on a pivot-hung door system.
- Stainless Steel Construction: The stainless steel finish provides superior resistance to corrosion, oxidation, and wear — making this pivot well-suited for environments with high humidity or heavy use.
- 4-Inch Pivot Size: The 4-inch format is designed for commercial-grade pivot-hung door assemblies requiring robust reinforcing hardware.
- McKinney Quality: McKinney is a recognized manufacturer of professional-grade door hardware, and the 5540 reflects their commitment to precision-engineered pivot solutions for commercial openings.
Applications
The McKinney 5540 heavy weight reinforcing pivot is appropriate for pivot-hung door installations in commercial, institutional, and high-traffic settings where the pivot point requires additional load support and long-term durability. Typical use cases include reinforcing pivot assemblies on heavy doors at top or intermediate pivot locations in buildings with frequent door operation cycles.
Technical Details
| Feature | Details |
|---|---|
| Brand | McKinney |
| Part Number | 5540 |
| Part Type | Hinge / Reinforcing Pivot |
| Pivot Size | 4 Inch |
| Finish / Material | Stainless Steel |
| Function | Heavy weight reinforcing pivot; carries and reinforces load at top or intermediate pivot point on pivot-hung doors |
| Intended Use | High-frequency pivot-hung door openings |
| Pivot Point Placement | Top or Intermediate |
Documentation
| Door Handing | LH or RH |
| Brand | McKinney |
| General - US Finishes | US32D - Satin Stainless Steel/ 630 |
| Hinge Height | 4.0" Hi |
| Hinge Grade/Thickness | Heavy Wt .180 to .190 |
| Base Material | Stainless Steel |
| Part Type | Hinge |
