McKinney RCT2714 3-1/2 x 3-1/2 Five-Knuckle Standard Weight Full Mortise Butt Hinge with Round Corners
The McKinney RCT2714 is a full mortise, five-knuckle standard weight ball bearing butt hinge measuring 3-1/2 inches by 3-1/2 inches with 1/4-inch round corners. Manufactured by McKinney — a trusted name in architectural door hardware — this hinge is engineered for reliable, long-service performance in commercial and institutional door applications. The full mortise configuration means both leaves are recessed flush into the door edge and frame, producing a clean, professional installation with no surface-mounted hardware exposed.
Institutional Grade Features & Benefits
- Five-Knuckle Construction: The five-knuckle barrel design distributes load evenly across the full hinge length, improving durability and reducing wear at the pivot point over the life of the door.
- Ball Bearing Operation: Integrated ball bearings provide smooth, low-friction swing on heavy-use doors, minimizing maintenance and prolonging hinge life in demanding environments.
- Standard Weight Profile: The 0.123-inch steel leaf thickness (per the McKinney full-line catalog) delivers a proven balance of strength and material efficiency suited to standard commercial door and frame applications.
- Full Mortise Design: Both leaves mortise fully into the door edge and frame face, creating a flush, tamper-resistant installation consistent with commercial architectural standards.
- 1/4-Inch Round Corners: The 1/4-inch radius round corner geometry on each leaf is compatible with standard commercial door and frame preparations, ensuring straightforward drop-in replacement or new installation.
- 3-1/2 x 3-1/2 Inch Size: A widely specified hinge size for standard commercial interior and exterior door applications, offering broad compatibility with common door and frame preparations.
- McKinney Quality: Backed by McKinney's full-line manufacturing heritage, the RCT2714 is built to consistent dimensional tolerances for reliable fit and repeatable installation across large projects.
Technical Details
| Feature | Details |
|---|---|
| Brand | McKinney |
| Model / Part Number | RCT2714 |
| Part Type | Full Mortise Butt Hinge |
| Hinge Size | 3-1/2 in. x 3-1/2 in. |
| Knuckle Count | Five-Knuckle |
| Weight Class | Standard Weight |
| Bearing Type | Ball Bearing |
| Corner Radius | 1/4 in. Round Corner |
| Installation Type | Full Mortise |
| Gauge / Leaf Thickness | 0.123 in. (per McKinney full-line catalog) |
| General - US Finishes | US26D - Satin Chrome or US10B - Oil Rubbed Bronze |
| Brand | McKinney |
| Hinge Type | Full Mortise |
| Hinge Mounting | Full Mortise |
| Door Handing | Field Reversible |
| Hinge Height | 3.5" Hi |
| Hinge Width | 3.5" Wi |
| Hinge Grade/Thickness | Standard Wt .119 to .146 |
| Hinge Corners | 1/4" Radius |
| Hinge Knuckle | 5 Knuckles |
| Base Material | Steel |
| Part Type | Hinge |
