McKinney TA5392 5x4-1/2 Three-Knuckle Heavy Weight Stainless Steel Beveled-Edge Anchor Hinge | Full Mortise
McKinney TA5392 5 x 4-1/2 three-knuckle heavy weight stainless steel beveled-edge anchor hinge.
Lead time: Normally ships in 2-3 business days via McKinney QuickShip; current lead time confirmed at order acknowledgment.
Tags :
McKinney TA5392 5x4-1/2 Three-Knuckle Heavy Weight Stainless Steel Beveled-Edge Anchor Hinge — Full Mortise
The McKinney TA5392 is a full mortise, three-knuckle heavy weight anchor hinge engineered for demanding, high-frequency door openings. Featuring concealed anchor tabs and a purpose-built beveled hinge-side edge, this hinge is designed specifically for doors with a beveled edge (1/8 in 2 in profile) — ensuring a precise, flush fit without field modification. Constructed from stainless steel with a leaf thickness of 0.190 in., the TA5392 delivers the rigidity and long-term durability required wherever consistent, reliable operation is non-negotiable.
Institutional Grade Features & Benefits
- Full Mortise Installation: Recesses completely into both the door edge and frame, providing a clean, professional appearance and maximum structural integrity at the hinge line.
- Three-Knuckle Heavy Weight Construction: The three-knuckle configuration combined with heavy weight steel stock distributes load across the full leaf, making the TA5392 well-suited for high-cycle, high-traffic openings.
- Concealed Anchor Tabs: Hidden anchor tabs lock the hinge firmly into the mortise pocket, resisting pull-out forces and maintaining alignment under sustained use — a hallmark of McKinney anchor hinge design.
- Beveled-Edge Profile (1/8 in 2 in): The factory-formed beveled hinge-side edge matches standard beveled door stiles, eliminating gaps and ensuring consistent, even bearing along the full hinge height.
- Stainless Steel Material: Corrosion-resistant stainless steel construction makes the TA5392 appropriate for environments where finish durability and hygiene are priorities.
- 0.190 in. Leaf Thickness: Heavy gauge steel leaves — at exactly 0.190 in. per the McKinney full-line catalog — provide the rigidity expected in institutional and commercial door hardware specifications.
- 5 x 4-1/2 Hinge Size: The 5-inch by 4-1/2-inch leaf dimensions accommodate wider, heavier door applications where standard-weight hinges are insufficient.
Technical Details
| Feature | Details |
|---|---|
| Brand | McKinney |
| Part Number | TA5392 |
| Part Type | Hinge — Full Mortise Anchor Hinge |
| Knuckle Count | Three-Knuckle |
| Weight Class | Heavy Weight |
| Hinge Size | 5 in. x 4-1/2 in. |
| Material | Stainless Steel |
| Gauge / Leaf Thickness | 0.190 in. (per McKinney full-line catalog) |
| Edge Profile | Beveled hinge-side edge for beveled doors (1/8 in 2 in) |
| Anchor Feature | Concealed anchor tabs |
| Intended Application | High-frequency openings with beveled-edge doors |
Documentation
- McKinney Catalog / Product Page - TA5392
- This model is a factory option (modified barrel/tip) of the base hinge; the McKinney document library publishes the cut sheet under the base model. The catalog page above carries the option's specification.
| Door Handing | LH or RH |
| Brand | McKinney |
| General - US Finishes | US32D - Satin Stainless Steel/ 630 |
| Hinge Type | Anchor |
| Hinge Mounting | Full Mortise |
| Hinge Height | 5.0" Hi |
| Hinge Width | 4.5" Wi |
| Hinge Grade/Thickness | Heavy Wt .180 to .190 |
| Hinge Corners | Square |
| Hinge Knuckle | 3 Knuckles |
| Base Material | Stainless Steel |
| Part Type | Hinge, Hinge |
