Sargent 68-2487 Chassis Assembly for 8300 Series Exit Device — RHRB

The Sargent 68-2487 is an OEM replacement Chassis Assembly engineered for the Sargent 8300 Series exit device. Also referenced as a Chassis Pack, this component serves as the core operating mechanism within the exit device body. When the push bar (push rail) is depressed, the chassis receives that force and retracts the latch bolt, enabling controlled, code-compliant egress. Designed and manufactured to Sargent's original equipment specifications, this part restores the exit device to full factory-level performance. This listing is for the Right Hand Reverse Bevel (RHRB) hand configuration.

Institutional Grade Features & Benefits

• OEM Replacement Precision: Manufactured to Sargent factory tolerances, ensuring a drop-in fit within the 8300 Series exit device without modification.
• Core Egress Mechanism: Transfers push-bar force directly to latch retraction, maintaining reliable, smooth exit operation every cycle.
• Restores Device Function: Replaces a worn, damaged, or failed chassis to bring the exit device back to full operational readiness — minimizing door hardware downtime in institutional and commercial facilities.
• Correct Handing — RHRB: Specified for Right Hand Reverse Bevel door applications; handing is pre-engineered into the chassis geometry for proper latch engagement.
• Compatible with 8300 Series: Directly supports the Sargent 8300 exit device, a widely installed rim-style exit device found in schools, hospitals, government buildings, and commercial facilities.
• Genuine Sargent Component: Sourced as an authentic Sargent part, preserving warranty integrity and compliance with the original door hardware specification.

Applications

This chassis assembly is the ideal service and maintenance part for facility managers, door hardware distributors, and commercial locksmiths maintaining Sargent 8300 Series exit devices on right hand reverse bevel doors. Common installation environments include schools and universities, healthcare facilities, commercial office buildings, government and municipal buildings, and retail and hospitality properties requiring dependable life-safety egress hardware.

Technical Details

Door Handing Reference

Parts List Illustration
