McKinney HT4A4795 4-1/2" Swing Clear Hospital Tip Hinge — Five-Knuckle Heavy Weight Ball Bearing, Beveled Edge
The McKinney HT4A4795 is a full-mortise, five-knuckle, heavy-weight ball bearing swing clear hinge engineered specifically for beveled-edge doors with hospital tips. Measuring 4-1/2 inches, this hinge is designed to swing a door fully clear of the door frame opening, delivering a true barrier-free clear width — a critical performance requirement in accessible, healthcare, and institutional environments where unobstructed passage is essential. The swing clear geometry ensures the door leaf rotates beyond the plane of the frame, maximizing the usable clear opening width without requiring a wider rough opening.
Institutional Grade Features & Benefits
- Swing Clear Design: Pivots the door completely clear of the opening to provide a full, unobstructed passage width — essential for ADA-compliant and barrier-free door openings.
- Five-Knuckle Heavy Weight Construction: The five-knuckle barrel provides superior strength and load distribution across the full height of the hinge, purpose-built for high-cycle, heavy-use door applications.
- Ball Bearing Operation: Integrated ball bearings deliver smooth, low-friction operation and extended service life, making this hinge well-suited for doors subject to frequent use.
- Hospital Tips: The hospital-tip (button-tip) profile eliminates exposed hinge pin projections, reducing the risk of clothing or equipment snagging — a standard specification in healthcare, assisted living, and institutional facilities.
- Beveled Edge Compatibility: Specifically designed for beveled-edge doors, ensuring a proper fit and flush mortise installation without modification.
- Full Mortise Installation: Mortises into both the door edge and the door frame for a clean, integrated appearance and maximum structural integrity.
- McKinney Quality: McKinney is a recognized name in commercial-grade hinge manufacturing, with a long history of supplying architectural hardware for demanding commercial and institutional projects.
Technical Details
| Feature | Details |
|---|---|
| Brand | McKinney |
| Model / Part Number | HT4A4795 |
| Part Type | Full Mortise Swing Clear Hinge |
| Hinge Size | 4-1/2 inch |
| Knuckle Configuration | Five-Knuckle |
| Weight Class | Heavy Weight |
| Bearing Type | Ball Bearing |
| Tip Style | Hospital Tip (Button Tip) |
| Door Edge Type | Beveled Edge |
| Mounting Type | Full Mortise |
| Primary Function | Swing clear for barrier-free clear opening width |
Applications
The McKinney HT4A4795 swing clear hinge is a go-to specification for projects requiring barrier-free door clearance on beveled-edge doors. Its hospital-tip profile and heavy-weight, ball bearing construction make it appropriate for institutional and commercial settings where durability, smooth operation, and accessible passage width are non-negotiable design criteria. The full mortise configuration suits standard commercial hollow metal and wood door frames.
Documentation
- McKinney Catalog / Product Page - HT4A4795
- No manufacturer cut sheet is published for this model in the McKinney document library; the catalog page above carries the spec.
| Brand | McKinney |
| General - US Finishes | US26D - Satin Chrome |
| Hinge Type | Swing Clear |
| Hinge Mounting | Full Mortise |
| Door Handing | Field Reversible |
| Hinge Height | 4.5" Hi |
| Hinge Width | 4.5" Wi |
| Hinge Grade/Thickness | Heavy Wt .180 to .190 |
| Hinge Corners | Square |
| Hinge Knuckle | 5 Knuckles |
| Base Material | Steel |
| Hinge Options | HT (Hospital Tip) |
| Part Type | Hinge |
