McKinney T4A4395 4-1/2" Swing Clear Hinge | Heavy Weight Five-Knuckle Stainless Steel Full Mortise Beveled Edge
McKinney T4A4395 4-1/2 five-knuckle heavy weight swing clear hinge beveled edge.
Lead time: Normally ships in 2-3 business days via McKinney QuickShip; current lead time confirmed at order acknowledgment.
Tags :
McKinney T4A4395 4-1/2" Swing Clear Hinge — Five-Knuckle Heavy Weight Stainless Steel Beveled Edge Full Mortise
The McKinney T4A4395 is a full mortise, five-knuckle, heavy weight stainless steel ball bearing swing clear hinge engineered for beveled-edge doors. Designed to swing the door fully clear of the doorway opening, the T4A4395 provides maximum barrier-free clear width — making it the preferred choice wherever accessible, unobstructed passage is required. As a full mortise hinge, it is recessed flush into both the door edge and the frame, delivering a clean, professional installation with superior load distribution.
Institutional Grade Features & Benefits
- Swing Clear Design: Swings the door completely clear of the opening, maximizing the usable clear width of the doorway for barrier-free and accessibility-compliant applications.
- Five-Knuckle Construction: The five-knuckle configuration provides a strong, stable pivot geometry that resists racking and wear over extended high-cycle use.
- Heavy Weight Classification: Built to handle demanding door weights and high-frequency use environments, offering long-term durability and reduced maintenance.
- Ball Bearing Operation: Integrated ball bearings ensure smooth, low-friction door swing and extend the operational lifespan of the hinge under heavy load conditions.
- Stainless Steel Material: Manufactured from stainless steel for outstanding corrosion resistance, making the T4A4395 well suited for environments where moisture or humidity is a concern.
- Beveled Edge Compatibility: Specifically designed for beveled-edge doors, ensuring proper fit and full bearing surface contact at the door edge.
- Full Mortise Installation: Mortised flush into both the door and frame for a secure, low-profile fit that maintains door alignment and structural integrity.
- McKinney Quality: Manufactured by McKinney, a respected name in architectural hardware with a long history of producing commercial and institutional grade hinges.
Technical Details
| Feature | Details |
|---|---|
| Brand | McKinney |
| Model / Part Number | T4A4395 |
| Part Type | Hinge — Full Mortise Swing Clear |
| Hinge Size | 4-1/2" |
| Knuckle Count | Five-Knuckle |
| Weight Class | Heavy Weight |
| Bearing Type | Ball Bearing |
| Material | Stainless Steel |
| Door Edge Type | Beveled Edge |
| Installation Type | Full Mortise |
| Function | Swing Clear — provides barrier-free clear opening width |
Documentation
- McKinney Catalog / Product Page - T4A4395
- No manufacturer cut sheet is published for this model in the McKinney document library; the catalog page above carries the spec.
| Brand | McKinney |
| General - US Finishes | US32D - Satin Stainless Steel/ 630 |
| Hinge Type | Swing Clear |
| Hinge Mounting | Full Mortise |
| Door Handing | Field Reversible |
| Hinge Height | 4.5" Hi |
| Hinge Width | 4.5" Wi |
| Hinge Grade/Thickness | Heavy Wt .180 to .190 |
| Hinge Corners | Square |
| Hinge Knuckle | 5 Knuckles |
| Base Material | Stainless Steel |
| Hinge Options | Swing Clear - Bev. Edge Dr |
| Part Type | Hinge |
