McKinney TA786 Concealed Bearing Hinge | 5" x 4-1/2" Heavy Weight 3-Knuckle
The McKinney TA786 is an industrial-strength, full-mortise architectural hinge designed for the most demanding high-traffic commercial environments. Featuring a sophisticated 3-knuckle design and advanced concealed bearings, this hinge provides a sleek, modern aesthetic while delivering the extreme load-bearing capacity required for heavy-duty openings. It serves as the premier solution for door restoration, offering a clean, high-end appearance for schools, hospitals, and government facilities that utilize 5-inch hinge preparations.
Engineered with vertical and lateral thrust twin anti-friction bearings at both joints, the TA786 ensures a lifetime of smooth, silent operation under heavy stress. These bearings are completely concealed within the knuckles, protecting them from environmental contaminants while providing a tamper-resistant solution for commercial door security. This hinge is a vital component for any solution for door surface repair, as its heavy .190 gauge thickness and standard template screw hole pattern allow for the seamless replacement of failed hardware on high-use metal or wood doors.
Key Features & Performance
- Concealed Anti-Friction Bearings: Features twin bearings hidden within the joints to manage heavy vertical and lateral thrust, acting as a permanent solution for door edge reinforcement.
- Heavy-Weight Construction: Built with a .190 gauge thickness, specifically engineered to withstand the rigors of high-traffic institutional use without sagging.
- Aesthetic 3-Knuckle Profile: Offers a contemporary, architectural look with a flush pin and non-rising steel pin for a clean, unbroken leaf line.
- Satin Chrome Finish (US26D): The high-quality plated finish acts as a durable remodeling scar plate, providing maximum resistance to corrosion and physical wear.
- Large Format Heavy-Duty Sizing: The 5" x 4-1/2" dimensions are ideal for tall, heavy, or high-frequency doors that require maximum structural support.
Technical Details & Specifications
- Brand: McKinney (ASSA ABLOY)
- Model Number: TA786
- Dimensions: 5" Height x 4-1/2" Width (Full Mortise)
- Finish: US26D (Satin Chrome)
- Bearing Type: Concealed Vertical & Lateral Thrust (TA Prefix)
- Knuckle Count: 3 Knuckle
- Thickness: Heavy Weight .190 Gauge
- ANSI Number: A8111
- Fasteners Included: Furnished with All Wood Screws (1-1/4" x 12 FPHW) and All Machine Screws (1/2" x 12-24 FPHM).
Why Choose the McKinney TA786?
The McKinney TA786 is the professional’s choice for projects that demand both high-performance durability and architectural elegance. While standard 5-knuckle hinges show visible bearing lines, the concealed bearing technology of the TA786 delivers a smooth, streamlined profile without compromising on strength. It offers a permanent and cost-effective solution for door security, providing the industrial-grade reliability and polished, high-end appearance required for modern institutional spaces.
| General - US Finishes | US26D - Satin Chrome |
| Brand | McKinney |
| Hinge Height | 5.0" Hi |
| Hinge Width | 4.5" Wi |
| Hinge Grade/Thickness | Heavy Wt .180 to .190 |
| Hinge Type | Full Mortise |
| Hinge Options | Concealed Bearing |
| Base Material | Steel |
| Hinge Corners | Square |
