McKinney TA795 Full Mortise Three-Knuckle Heavy Weight Swing Clear Hinge | ANSI A8121 | Reversible
McKinney TA795 5 three-knuckle heavy weight reversible swing clear hinge.
Lead time: Normally ships in 2-3 business days via McKinney QuickShip; current lead time confirmed at order acknowledgment.
Tags :
McKinney TA795 Full Mortise Three-Knuckle Heavy Weight Swing Clear Hinge
The McKinney TA795 is a full mortise, three-knuckle, heavy weight ball bearing swing clear hinge engineered to swing a door fully clear of the door opening, maximizing the usable clear width of the passage. Also referenced as the TA795 Swing Clear Hinge, this reversible design accommodates either hand without the need for separate left-hand or right-hand inventory, simplifying specification and stocking for commercial and institutional door openings. As a full mortise hinge, it is set flush into both the door edge and the door frame for a clean, professional installation.
Institutional Grade Features & Benefits
- Swing Clear Design: Pivots the door completely clear of the opening, delivering the maximum unobstructed clear width — a critical requirement for accessible, barrier-free doorways that must accommodate wheelchairs, medical equipment, and wide-load traffic.
- Three-Knuckle Configuration: The three-knuckle barrel provides a clean, architectural profile while maintaining robust structural integrity suited to heavy-duty commercial applications.
- Heavy Weight Construction: Built to handle demanding door weights and high-cycle environments found in commercial, institutional, and industrial facilities.
- Ball Bearing Operation: Precision ball bearings reduce friction and wear, ensuring smooth, quiet door swing and long service life with minimal maintenance.
- Reversible Handing: A single SKU installs on both left-hand and right-hand doors, reducing the need for separate hinge inventory and simplifying procurement and project management.
- Full Mortise Installation: Recessed flush into door edge and frame for a secure, low-profile fit that maintains door edge integrity and aesthetics.
- McKinney Quality: Manufactured by McKinney, a long-established name in commercial door hardware, the TA795 meets the expectations of architects, contractors, and facility managers specifying durable, code-conscious hinge solutions.
Applications
The McKinney TA795 swing clear hinge is the preferred choice wherever maximizing the functional clear width of a door opening is essential. Typical applications include accessible restroom entries, healthcare and hospital corridors, educational facilities, government buildings, and any commercial opening required to meet barrier-free accessibility guidelines. Its heavy weight rating makes it equally appropriate for solid-core wood doors and hollow metal doors in high-traffic environments.
Technical Details
| Feature | Details |
|---|---|
| Brand | McKinney |
| Part Number | TA795 |
| Part Type | Hinge |
| Hinge Type | Full Mortise Swing Clear |
| Knuckle Configuration | Three-Knuckle |
| Weight Class | Heavy Weight |
| Bearing Type | Ball Bearing |
| Handing | Reversible (Left-Hand & Right-Hand) |
| Function | Swings door fully clear of opening for barrier-free clear width |
Documentation
| Brand | McKinney |
| General - US Finishes | US26D - Satin Chrome |
| Hinge Type | Swing Clear |
| Hinge Mounting | Full Mortise |
| Door Handing | Field Reversible |
| Hinge Height | 5.0" Hi |
| Hinge Width | 5.0" Wi |
| Hinge Grade/Thickness | Heavy Wt .180 to .190 |
| Hinge Corners | Square |
| Hinge Knuckle | 3 Knuckles |
| Base Material | Steel |
| Part Type | Hinge |
